Product Description:
Our Polyimide Film Adhesive Tape has a Tensile Strength of
≥42N/10mm, which means it can withstand pressure and tension
without breaking or tearing. This feature makes it ideal for
applications that require a high level of durability.
The Temperature Range of our Polyimide Film Adhesive Tape is
-73℃~280℃, making it suitable for use in extreme temperatures. It
can withstand both low and high temperatures without losing its
adhesive properties, making it a reliable choice for various
applications.
Our Polyimide Film Adhesive Tape has a Dielectric Strength of
≥80KV/mm, which means it can resist electrical
breakdown(BDV>4kv). This feature makes it an excellent choice
for slot liner insulation, where electrical insulation is
necessary.
The Elongation of our Polyimide Film Adhesive Tape is ≥40%, which
means it can stretch and bend without breaking. This feature makes
it an excellent choice for applications that require flexibility
and movement.
Our Polyimide Film Adhesive Tape is a reliable and cost-effective
solution for various electronic applications. Its high-performance
features make it an ideal choice for slot liner insulation,
coverlay or stiffener in F-PCB, and other applications where
durability, temperature resistance, and electrical insulation are
essential.
Features:
- Product Name: Polyimide Film Adhesive Tape
- Dielectric Strength: ≥80KV/mm
- Material: Polyimide Film
- Adhesive: Pressure Sensitive Silicone Adhesive
- Adhesion: ≥2.2N/10mm
- Low temperature resistant
- High temperature resistant
- Excellent balance of electrical, chemical and physical property
Technical Parameters:
| RoHS Compliant | Yes |
| Material | Polyimide Film |
| Elongation | ≥40% |
| Color | Amber |
| Insulation Resistance | ≥10^13Ω |
| Halogen Free | Yes |
| Adhesive | Pressure Sensitive Silicone Adhesive |
| Dielectric Strength | ≥80.0KV/mm |
| Adhesion | ≥2.2N/10mm |
| Thickness | 55um~70um |
This Polyimide Film Adhesive Tape is suitable for wire & cable
insulation, slot liner insulation and other applications where high
temperature resistance and excellent electrical insulation
properties are required.
Applications:
With a thickness range of 55um~70um, the product is suitable for
use as a coverlay or stiffener in F-PCBs. It provides excellent
insulation to circuitry and helps to protect against damage from
environmental elements such as moisture or dust.
The temperature range of -73℃~280℃ makes the Polyimide Film
Adhesive Tape ideal for use in both high and low-temperature
environments. This makes it perfect for applications such as wire &
cable insulation, where it provides a reliable and durable
insulation solution.
With an elongation of ≥40%, the tape is flexible and can conform
easily to irregular surfaces. This makes it perfect for use in
complex applications where a high degree of flexibility is
required.
Overall, the Polyimide Film Adhesive Tape is a versatile product
that can be used in a wide range of applications. It is perfect for
use as a coverlay or stiffener in F-PCBs, wire & cable insulation,
and other applications where high-temperature resistance,
flexibility, and durability are required.
